Measurement range
|
50mV/m to 11V/m
|
|
Display
|
4½ digits maximum reading 19999
|
|
Frequency range
|
10MHz~8GHz
(accuracy :±1dB at 2.45GHz)
|
|
Measurement units
|
mV/m, V/m, µA/m, mA/m,
µW/m², mW/m²,µW/cm²
|
|
Display resolution
|
0.1mV/m, 0.01V/m,
0.1µA/m, 0.001mA/m, 0.001µW/m², 0.01mW/m²,
0.001µW/cm² |
|
Manual data memory
|
200 data sets
|
|
Alarm function
|
Adjustable threshold with ON/OFF
|
|
Memory recall
|
Adjustable
|
|
Calibration factor CAL
|
The CAL setting range is from 0.10~5
|
|
Sampling time
|
3 times per second
|
|
Operating temperature
and humidity
|
0°C~50°C (32°F~122°F),
25% ~75% RH
|
|
Power supply
|
9V battery
(NEDA 1604 IEC 6F22 JIS 006P) |
|
Battery life
|
Approx. 3hours
|
|
Dimension
|
370x80x80mm (LxWxH)
|
|
Weight
|
Approx.400g (including battery)
|
Features
-
Measurement range: 38mV to 11V/m
-
Frequency range: 10MHz~8GHZ ~8GSensor: Triple Axis (X, Y, Z).
-
Manual data memory (Max & AVG) records.
-
Calibration factor, Alarm and Clock settings.
